Depict an image of one of the largest tunnel boring machines named as 'Yellow Gang Road Shield Machine', characterized by being a mixed-type slurry balance shield machine. The machine has an excavation diameter of 17.4 meters, total length approximately 140 meters, and total weight around 6000 tons. It features a pipe segment with an external diameter of 16.8 meters, internal diameter of 15.4 meters, and a length of 2 meters, with the maximum weight of a single piece being 15.6 tons. The cutter head is designed in a radial pattern, divided into a central piece and four circumferential pieces. The shield body, with a diameter of 17.375 meters, is divided into 12 parts connected by bolts, with the central shield body being 14.9 meters long and the total weight of the shield body being 3330 tons. It is built with a retractable main drive, with 18 main drive expansion cylinders providing a total thrust of 7910 tons. Total power reaches 5600 kilowatts. The machine also employs 34 sets of thrust cylinders with a total thrust reaching up to 34800 tons. The shield machine adopts a vacuum suction cup assembly machine, with a total installed power of 10,800 kilowatts. This machine is the largest diameter shield machine for tunneling under the Yellow River.
