Digital Logic Circuit with NAND and XOR Gates

Prompt

A high-detailed illustration of a digital logic circuit configuration featuring a NAND gate connected to an XOR gate. Let's envision the NAND gate on the left side of the image, portrayed with its standard symbol of an oval connected to an inverted triangle. Two input lines are leading into it, and one output line extends from it, moving to the right. This line then connects to an XOR gate, depicted by a rectangle with a curved side on the left. The XOR gate also has two input lines connecting to it and one output line leading out from the right side of it. The image should provide a clear representation of how these two logic gates interact within a circuit.
